Product
On-board assembly line

On-board assembly line

Clean and tear film, lock, AA, oven, airtight, function test, internal reference calibration
MORE
RSCZCX01 on-board whole line

RSCZCX01 on-board whole line

The assembly line consisting of AA loading machine, AA machine, oven, oven loading and unloading machine is compatible with vehicle-mounted camera:
MORE
Function tester

Function tester

Function: Color difference, gray scale, white balance, resolution, black and white field, angle, working current, signal to noise ratio FOV test light source: FOV test. Flat chart light source: SFR/MTF, color card, gray scale, OC, FOV (when FOV is less than 90 degrees) test. Collimator: SFR/MTF when FOV is greater than 90 degrees White field: white balance, stain, bad spot test Black field: bright spot lighting fixture: voltage, current, lighting test
MORE
Screw locking machine

Screw locking machine

Function Intelligent electric screwdriver is adopted, which can programmatically control the torque of electric screwdriver and set relevant parameters of locking screw characteristic Screw worker and material machine feed separately Electric batch has locking parameter feedback and defect monitoring function Visual precision positioning; UPH 80-100 pcs/h。
MORE
RSLH06 aging machine

RSLH06 aging machine

Function: It is mainly used for aging test of vehicle module, and test the frame rate, voltage, current, etc. of the product 6 independent temperature control adjustable A single cabin supports 16 products, a total of 96 products It is compatible with LVDS, DVP and MIPI formats. When switching between different products, you only need to replace the socket and the serial board Frame loss/current/voltage/lighting failure, save relevant records and generate test report UPH: 96pcs at a time (floating according to aging time)
MORE
Full-automatic dual-station AA equipment

Full-automatic dual-station AA equipment

This device is mainly used in the alignment and assembly process of mobile phone camera module; It includes automatic alignment system, automatic dispensing system, UV curing system, automatic loading and unloading system, etc.
MORE
Full-automatic wide-angle AA equipment

Full-automatic wide-angle AA equipment

This equipment is used for the alignment and assembly of large wide-angle mobile camera module; It includes automatic alignment system, automatic dispensing system, UV curing system, automatic loading and unloading system, laser height measurement module and other systems.
MORE
Stray light detector

Stray light detector

function It is used to detect the optical characteristics of mobile phone camera module. It includes automatic loading and unloading system and optical detection system. characteristic Full-automatic loading and unloading system; Equipped with professional LED backlight and self-developed test software; Detection accuracy: detection rate 100%, passing rate ≤ 5%, repeatability 100%; UPH more than 1500 per hour.
MORE
Lens detection equipment

Lens detection equipment

function It is used for camera module lens focusing detection, mainly including automatic feeding system, automatic sorting system, automatic detection system, etc. characteristic Two-station detection; AA alignment accuracy: X Y Z: 1um; α β 0.003°； Rotation accuracy theta 0.003 °; Support maximum visual angle (FOV) 90 °; Simulation distance 1.5m~∞; UPH ≥1000 pcs/h 。
MORE
Lens blowing machine

Lens blowing machine

It is used to purge the dust on the lens surface of the camera module. Features Manual loading and unloading, double station secondary dust blowing; The position and angle of the air knife can be adjusted; It is equipped with water flow to take away the floating dust and purify the air for discharge; Cleanliness rate ≥ 98%; UPH 500~520 disks per hour.
MORE
< 12 > proceed page
